M16 2pin Plastic Connector Electrical Wire Connector Assembly Insulation Watertight Connector thumbnail

M16 2pin Plastic Connector Electrical Wire Connector Assembly Insulation Watertight Connector

Category: Waterproof Circular Connectors

Series: M16 | Structure: Push-Lock

Model: LLT-M16-15002F1031

Need Quotation or Sample?

Click Get My Contact to reveal the contact linked to the publisher of this product.

Publisher: TonyTang

Please share your project requirement and quantity for quotation.

M16 2pin Plastic Connector Electrical Wire Connector Assembly Insulation Watertight Connector
This M16-2pin field assembly connector can get IP67/IP68 waterproof protection . under the normal temperature,plug the male female connector put into the 1m depth water ,after 4 hours inner connector have no immersion happened. It is very convenient to assemble . The male mate female through push lock . attach cable by solder .We have 5.5/6.5/7.2/8.5mm grommet can fit your different diameter cable . Our factory specilize in this field around twenty five years ,we rank in the top manufacturer .We Own full sets certificate ,such as UL,TUV,CE Rohs,SAA, CCC conform to to all market ;We can provide competitive price ;Support ODM,OEM ,customized design;100% quality guarantee ,12 months warranty ;Reliable after-sales service ,salesman 24 hours on line .

Technical Specs

Product Size

M16

Pin

2pin

IP Rating

IP67/IP68

Rated Current

15A

Rated Voltage

300V

Product Series

M16

Wiring Type

Soldering

Interface Type

Push lock

Mating Cycles

>=3000 times

Complies with product certification:

UL TUV CQC CE RoHS REACH

System certification:

IATF 16949 ISO 13485 ISO 9001 ISO 14001 ISO 50001 ISO 45001
