LLT 2pin M16 Male Female Electrical Wire IP687 Waterproof Connector

LLT 2pin M16 Male Female Electrical Wire IP687 Waterproof Connector is a published reference for cable-to-cable transitions in outdoor and industrial equipment. The visible configuration highlights sealing around IP67/IP68, 15A current range, 2pin pin layout, 2-12pin and 2+2/2+3/2+4/3+3/2+8pin interface. Termination direction is by solder, which should be checked against the actual harness build.

IP67 Waterproof Connector M16 Threaded Model: LLT-M16-15002F1051
M16 / Threaded LLT 2pin M16 Male Female Electrical Wire IP687 Waterproof Connector

Connector Gallery

Request Product Contact

Reveal the sales contact linked to this product page for quotation and technical discussion.

Publisher: TonyTang

Please share your project requirement and quantity for quotation.

Technical Specs

Product Size

M16

Pin

2pin

IP Rating

IP67/IP68

Rated Current

15A

Rated Voltage

300V

Product Series

M16

Wiring Type

by Solder

Interface Type

2-12pin and 2+2/2+3/2+4/3+3/2+8pin

Mating Cycles

>=3000 times

Complies with product certification:

UL TUV CQC CE RoHS REACH

System certification:

IATF 16949 ISO 13485 ISO 9001 ISO 14001 ISO 50001 ISO 45001

Product Overview

Connector application and structure details

M16-2pin Field Assembly Thread lock Solder Wire Connector This M16-2pin solder-type field assembly connector is a 16mm circular industrial connector engineered for on-site soldering termination. Adhering to IEC 61076-2-106 standards, it is specially designed for 2-core power or signal wiring, widely used in outdoor and industrial environments. Core Features 1. Solder Termination Design Professional solder wire structure enables stable manual wiring on site. The contact terminals are easy to tin and connect, delivering excellent electrical conductivity and anti-loosening performance after soldering. No crimp tools are required, suitable for on-site maintenance and custom cabling. 2. Superior Sealing & Protection Equipped with high-performance rubber sealing rings and cable glands, it reaches IP67 waterproof and dustproof rating. It resists water splashes, dust and moisture intrusion, working steadily in outdoor, damp and dusty scenarios. 3. Durable Material & Structure • Housing: High-strength PA66 plastic, anti-vibration, impact-resistant and corrosion-proof. • Contacts: copper with gold plating, low contact resistance, anti-oxidation, supporting over 3000 mating cycles. Electrical Specifications • Rated voltage: 300V AC/DC • Rated current: 5A ~ 15A • Insulation resistance: ≥100 MΩ • Withstand voltage: 1500V AC for 1 minute • Working temperature: -25℃ ~ +85℃ • Applicable cable diameter: 4mm - 8mm Main Applications Industrial sensors, actuators, outdoor LED lighting, solar equipment, monitoring systems, telecommunication facilities and field electrical devices. Advantages Simple on-site soldering operation, reliable connection, strong environmental adaptability and long service life. It effectively reduces spare part inventory and maintenance costs, being a practical solution for field wiring projects. Short Marketing Version (for catalog & product label) M16-2pin field assembly solder wire connector features easy on-site soldering termination, IP67 waterproof & dustproof performance. Built with gold-plated contacts for stable power and signal transmission. Rugged structure withstands vibration and harsh weather. Ideal for industrial automation, outdoor lighting, solar systems and field electrical connections. Ultra-concise Version (for product title/banner) M16 2-Core Solder Type Field Assembly Connector | IP67 Waterproof, Industrial Grade for Power & Signal Wiring
