LLT 3pin M8 right angle male panel electrical cable connector

M8‑3Pin Right Angle Panel Cable Connector 1. Product Overview This M8‑3Pin right‑angle panel cable connector is an circular industrial sensor connector with 90‑degree angled cable outlet, integrated with pre‑molded cable for panel‑mount installation. The L‑shaped structure optimizes internal space inside equipment and avoids sharp‑angle wire bending stress. It adopts screw‑locking mechanism and IP67 sealing performance, delivering stable signal and low‑power power transmission for compact automation devices in harsh industrial environments. 2. General Specifications • Product Model: M8‑3Pin Right Angle Panel Cable Connector • Connector Type: Right‑angle male panel‑mount cable socket • Mounting Method: Front panel mount • Locking Mechanism: Screw locking • Number of Contacts: 3‑pin • Reference Standard: IEC 61076‑2‑104 3. Electrical Characteristics • Rated Current: 5A per pin (25℃) • Rated Voltage: 60V DC / 60V AC • Withstand Voltage: 1500V AC, 60s • Insulation Resistance: ≥1000 MΩ • Contact Resistance: ≤5 mΩ • Application: Sensor signal & low‑voltage power connection 4. Mechanical Properties • Housing Material: Nickel‑plated brass (metal coupling nut) • Contact Material: Copper alloy, gold‑plated • Insulator Material: High‑temperature resistant PA66 • Sealing Material: O‑ring • Cable Jacket: PUR / PVC (optional) • Cable OD: Φ3.5‑5.0 mm • Mating Cycles: ≥2000 times • Vibration Resistance: Compliant with IEC 60512‑6 5. Environmental Performance • Ingress Protection: IP67 (fully mated and locked condition) • Operating Temperature: ‑40℃ ~ +105℃ • Storage Temperature: ‑45℃ ~ +110℃ • Relative Humidity: 5%‑95% RH, non‑condensing • Pollution Degree: Level 3 6. Standard Pin Assignment • Pin 1: VCC / Power Positive (Brown) • Pin 3: GND / Power Negative (Blue) • Pin 4: Signal Output (Black) 7. Key Features 1. 90° right‑angle cable exit, saves internal installation space 2. Nickel‑plated brass metal lock‑nut, high mechanical strength and anti‑corrosion 3. Pre‑molded one‑piece cable‑connector structure for easy wiring 4. Front‑panel mounting design, fast assembly on equipment casing 5. Screw‑locking design prevents loose connection under vibration 6. Gold‑plated contacts for stable conductivity and anti‑oxidation 7. IP67 waterproof & dustproof, suitable for wet and dusty industrial sites 8. Compact dimension for miniature sensors and compact control devices 8. Application Fields • Industrial proximity sensors & photoelectric sensors • Factory automation control systems • Packaging machinery, textile equipment • Intelligent measuring instruments • Outdoor monitoring & low‑voltage control units • Horticulture lighting automation wiring systems 9. Certification & Customization • Certification: CE, REACH compliant • Standard Cable Length: 2m, 3m, 5m, 10m • Custom Service: Cable length, cable material, wire gauge, pin‑out and laser logo are available upon request Note: Above parameters are typical industry values, can be revised according to actual test data of your products.
