LLT M12 8pin IP68 Waterproof Multi pin Bulkhead Female Panel Mount Connector

LLT M12 8pin IP68 Waterproof Multi pin Bulkhead Female Panel Mount Connector is a published reference for control cabinets and machine enclosures requiring front-to-rear sealed interfaces. The visible configuration highlights sealing around IP67/IP68, 5A current range, 8 pin layout, 2 to 8pin and 2+2/2+3/2+4pin interface. Termination direction is by solder, which should be checked against the actual harness build.

Multi Pin Connectors Waterproof M12 Threaded Model: LLT-M12-05008F2961
M12 / Threaded LLT M12 8pin IP68 Waterproof Multi pin Bulkhead Female Panel Mount Connector

Connector Gallery

Request Product Contact

Reveal the sales contact linked to this product page for quotation and technical discussion.

Publisher: TonyTang

Please share your project requirement and quantity for quotation.

Technical Specs

Product Size

Fit max cable OD 5.8mm

Pin

8

IP Rating

IP67/IP68

Rated Current

5A

Rated Voltage

60V

Product Series

M12

Wiring Type

by Solder

Interface Type

2 to 8pin and 2+2/2+3/2+4pin

Mating Cycles

>=3000 times

Complies with product certification:

UL TUV CQC CE RoHS REACH

System certification:

IATF 16949 ISO 13485 ISO 9001 ISO 14001 ISO 50001 ISO 45001

Product Overview

Connector application and structure details

This M12-8pin female rear panel connectorcan get IP67/IP68 waterproof rate, male connector mate female connector via thread lock.The body matrial is PA66,V-0 fire retardant.Conduct material is plated gold brass.It can burden 5A/110V, This model 2-8pin and 2+2/2+3/2+4pin can be choice, the Work temperature is Minus 25℃ to 105℃. It is widely used in Grow light, LED light,Outdoor light,Signal transmission,Power drive,Illuminating industry and et cetera.We have cooperated with domestic and abroad customer, winning many project,such as Beijing Olympic Game Stadium,Bird's Nest,Water Cube,Bangkok New International Airport,Shanghai World Expo and etc, I wish we can win your project,looking forward to cooperating with you.
