LLT multi pin 10pin female panel mount quick lock 5A ampere signal data socket

Name: LLT multi pin 10pin female panel mount quick lock 5A ampere signal data socket
Brand: Shenzhen LLT Connector Co., Ltd.
SKU: LLT-M19-05010F2881

LLT multi pin 10pin female panel mount quick lock 5A ampere signal data socket is a published reference for industrial ethernet links in outdoor or washdown-prone equipment. The visible configuration highlights sealing around IP67/IP68, 5A current range, 10pin pin layout, 2-18pin/2+4/2+5/3+5pin interface. Termination direction is by solder, which should be checked against the actual harness build.

Multi Pin Connectors Waterproof M19 Bayonet Model: LLT-M19-05010F2881

M19 / Bayonet LLT multi pin 10pin female panel mount quick lock 5A ampere signal data socket

Request Product Contact

Reveal the sales contact linked to this product page for quotation and technical discussion.

Publisher: TonyTang

Please share your project requirement and quantity for quotation.

Technical Specs

Complies with product certification:

UL TUV CQC CE RoHS REACH

System certification:

IATF 16949 ISO 13485 ISO 9001 ISO 14001 ISO 50001 ISO 45001

Product Overview

Connector application and structure details

M19-10pin Female Panel Mount Connector Structure Circular panel female socket with 10 signal contacts, front/rear panel mounting optional. Adopts bayonet or push-pull lock structure for secure connection, widely used for signal & low-current transmission. Electrical Parameters • Rated Voltage: 250V AC • Rated Current: 5A per pin • Contact: Solid copper with gold plating, anti-corrosion and low resistance • Contact Resistance: ≤8mΩ • Insulation Resistance: ≥1000MΩ • Withstand Voltage: 1200V AC / 1min • Mating Lifespan: ≥1000 insert/extract cycles Mechanical & Environmental • Protection Class: IP67 when fully mated • Housing: Flame-retardant PA66 nylon, impact resistant • Seal: High-elastic silicone gasket • Operating Temperature: -40℃ ~ +105℃ • Termination: Screw terminal, fits 16–24 AWG multi-core cables Compliance & Application Certified with RoHS, CE standards. Perfect for LED grow light control systems, industrial sensors, automation equipment, outdoor monitoring, lighting dimming signal transmission.

Application Fit

Typical application directions

Industrial Ethernet links in outdoor or washdown-prone equipment
Control cabinets, gateways, and monitoring nodes that need ingress protection
Projects targeting IP67/IP68 sealing performance and repeatable field mating.
Applications that need a connector architecture aligned with 5A current requirements.
