LLT M16 Multipin Connector 12pin 5A IP68 signal Data Plug Male Female Electrical Wire Connector

Name: LLT M16 Multipin Connector 12pin 5A IP68 signal Data Plug Male Female Electrical Wire Connector
Brand: Shenzhen LLT Connector Co., Ltd.
SKU: LLT-M16-05012F1051

LLT M16 Multipin Connector 12pin 5A IP68 signal Data Plug Male Female Electrical Wire Connector is a published reference for industrial ethernet links in outdoor or washdown-prone equipment. The visible configuration highlights sealing around IP67/IP68, 5A current range, 12pin pin layout, 2-12pin/2+2/2+3/2+4/3+3/2+8pin interface. Termination direction is by solder, which should be checked against the actual harness build.

Multi Pin Connectors Waterproof M16 Threaded Model: LLT-M16-05012F1051

M16 / Threaded LLT M16 Multipin Connector 12pin 5A IP68 signal Data Plug Male Female Electrical Wire Connector

Request Product Contact

Reveal the sales contact linked to this product page for quotation and technical discussion.

Publisher: TonyTang

Please share your project requirement and quantity for quotation.

Technical Specs

Complies with product certification:

UL TUV CQC CE RoHS REACH

System certification:

IATF 16949 ISO 13485 ISO 9001 ISO 14001 ISO 50001 ISO 45001

Product Overview

Connector application and structure details

The M16-12pin is a 16mm threaded circular signal connector (12 contacts), build for industrial signal transmission. • 12 contacts (A-coded)：Multi-channel signal transmission; prevents mismating. • IP67 protection：Dust-tight, resistant to moisture and temporary immersion. • Robust build：Nickel-plated alloy housing; gold-plated brass contacts (low resistance, anti-oxidation). • Electrical specs：60V AC/DC, 5A per contact; insulation resistance ≥100MΩ. • Temperature range：-25°C to +85°C. • Termination：Solder, or field-wireable; panel/cable mount options. Applications • Industrial automation (sensors, actuators) • Machinery & robotics • Test & measurement equipment • Outdoor/harsh-environment devices Benefits • Compact & reliable：16mm thread, vibration-resistant screw lock. • Stable signal：Gold plating ensures low contact resistance and integrity. • Easy integration：Front/back panel mount, cable plug variants.

Application Fit

Typical application directions

Industrial Ethernet links in outdoor or washdown-prone equipment
Control cabinets, gateways, and monitoring nodes that need ingress protection
Projects targeting IP67/IP68 sealing performance and repeatable field mating.
Applications that need a connector architecture aligned with 5A current requirements.
